Carleader 1080P AHD Quad Split Control Box With Recording Function: Your All-in-One Vehicle Surveillance Hub

Elevate vehicle surveillance system with Carleader 1080P AHD Quad Split Control Box With Recording Function, a versatile 4CH video splitter box integrated with advanced DVR recording capabilities. Designed for reliable, flexible, and high-definition monitoring, this compact unit ideal for fleet management, security vehicles, or any application requiring multi-camera inputs recording and display system.

Introduction:

* 4 Channels HD Input: four channels cameras inputs (simultaneously at resolutions up to 1080P, 720P, or D1, support mixed signal). The unit automatically segments the quad display for comprehensive vision.

* Integrated DVR Recording: Support Loop recording function, records footage directly onto a TF card, maximum capacities of 512GB for extended recording times.

* Different Output Options: Carelader offers CVBS or AHD1080P video output for option. (The AHD 1080P output is able to backward compatible with CVBS / 720P / 1080P at 25/30fps).

* Precise Image Control: Separately adjustable for screen brightness, contrast, saturation, hue, and sharpness settings for each camera channel, ensuring optimal image quality in various conditions.

Features:

* 4CH camera can be triggered separately and displayed in full screen automatically

* The video output can be set TOP / Bottom / Left and Right deflate.

* Capable of switching normal or mirror image separately for each camera channel.

* Quad Splitter Box with wide voltage range (DC 9V-32V) suitable for various vehicle electrical systems.

* Video output connector support 4-pin aviation male connector.

* Global Compatibility: Supports both PAL and NTSC video formats auto switch.

* Carleader Splitter Box features with high or low voltage protection and overload protection for enhancing durability and safety.

* Compact & Durable: Housed in a compact and rugged enclosure measurement of 155 x 87 x 32 mm.

Ideal Applications:

This quad splitter box ideal for Commercial Trucks & Fleets, Buses & Coaches, Emergency & Security Vehicles, Construction and Heavy Equipment, any other vehicle that require multiple camera display and recording function

Why Choose the Carleader 1080P AHD Quad Split Control Box With Recording Function?

Carleader Quad Video Splitter Box combines the convenience of a 4CH video splitter box with the security of DVR recording function. Its comprehensive feature set, including separate image setting, flexible trigger modes (trigger wire & remote control), screen edge adjustment, wide voltage input, and robust protection – provides a reliable and high-quality surveillance solution tailored for the demanding mobile environment. Ensure complete situational awareness and secure video evidence with Carleader 1080P AHD Quad Split Control Box With Recording Function.
