10.1 Inch 2CH AHD Inputs Vehicle Backup Monitor

Carleader 10.1 Inch 2CH AHD Inputs Vehicle Backup Monitor, 2 AHD video inputs with 2 trigger wires, AHD 1024x600 resolution, suitable for trucks, buses, vans, RVs, etc. Welcome to ask and inquiry.

Model:CL-S1020AHD

Send Inquiry

Product Description

Carleader New 10.1 Inch 2CH AHD Inputs Vehicle Backup Monitor provided high definition and real-time performance, greatly improves the safety and convenience of reversing operations, becoming an indispensable safety auxiliary tool for drivers.

Parameter:

10.1 Inch 2CH AHD Inputs Vehicle Backup Monitor
Model	CL-S1020AHD
Screen Type	10.1 inch IPS LCD panel
Aspect Ratio	16 : 9
Resolution	1024 x 600 (RGB)
Brightness	550 cd/m2
Contrast	500 : 1
Video Input	Support 2CH / 3CH AHD 1080P/720P/CVBS Mixed Video Signal Input available With 2 / 3 x trigger wires, CH2 has trigger priority
Speaker	Optional (Without as default)
Audio Mode (If With Speaker)	CH1 with audio function
Auto Dimming	Optional (Without as default)
Remote Control	Yes, Package include 1x remote
OSD Menu	Image Setting, Image mirrored, Blue/Black Screen (No Signal), Multi-Language Setting, Trigger Delay, Parking Guide Line On/Off, Reset
Parking Guide Line	Each channel is adjusted separately, activated when trigger the trigger wire (Off as default)
Mirror / Normal Image	Each channel is adjusted separately (Mirror image as default)
System	PAL / NTSC auto switch
Button Type	Click buttons, each button with backlight
Power Supply	DC 9~32V
Connection Plug (Connector)	4PIN aviation connector as default, customized to RCA connector available
Operating Temperature	-20°C~+70°C (RH0%-RH90%)
Storage Temperature	-30°C~+80°C (RH0%-RH90%)
Warranty	2 Years
Dimension	25 x 16.5 x 3.0 cm (without shade) 25.5 x 17 x 6.5 cm (with shade)
