1080P Starlight Front Rear View Vehicle Camera with 170° Wide Angle

Carleader 1080P Starlight Front Rear View Vehicle Camera with 170° Wide Angle which is designed for professional vehicle video monitoring systems where a wide and clear viewing area is required. The camera supports CVBS, AHD720P and AHD1080P video configurations. The Starlight Color Night Vision function helps provide clearer color images in low-light environments. The camera offers a 120° viewing angle as standard, with up to 170° optional, helping cover a wider monitoring area. Its 180° tilt adjustment allows installers to easily adjust the camera direction according to different vehicle installation positions. With IP69K waterproof protection, the camera is suitable for demanding outdoor vehicle environments.

Product Features

• Provides color image performance in low-light environments, improving visibility during nighttime vehicle operation.
• The standard 120° viewing angle can be upgraded to 170°, providing broader front or rear vehicle coverage.
• The camera can be tilted up to 180°, allowing flexible adjustment of the monitoring direction during installation.
• Supports CVBS / AHD720P / AHD1080P, making it compatible with different vehicle monitoring systems.
• The IP69K vehicle camera is designed to withstand demanding outdoor conditions, making it suitable for commercial vehicles and fleet applications.
• Power consumption is only 60mA, helping reduce the power load on vehicle monitoring systems.
• Supports mirror image and non-mirrored image options for different front-view and rear-view applications.

Product Parameter

Product Type: Front & Rear View Vehicle Camera

Video Input: CVBS / AHD720P / AHD1080P Optional

Power Supply: DC12V (Standard), 24V (Optional)

Mirror Image: Optional

Non-Mirrored Image: Optional

System: PAL/NTSC Optional

View Angle: 120°(170° Optional)

S/N Ratio: More than 50dB (AEC Off)

Night Vision: Starlight Night Vision (Color Image)

White Balance: Auto

Electronic Shutter: Auto / 1/150 (1/60) - 1/100,000 sec

Backlight Compensation: Auto

Tilt Adjusting: 180°

Video Output: 1Vp-p 75Ω Composite, 4-Way DIN Jack ×1

Built-in Mic: No

Power Consumption: 60mA

Waterproof Rating: IP69K

Operating Temperature: -20℃~+75℃ (RH95% Max.)

Storage Temperature: -30℃~+85℃ (RH95% Max.)

Application Scenarios

• Truck Front & Rear Monitoring

Used for front and rear monitoring on trucks and heavy commercial vehicles.

• Bus Surveillance

Provides additional visibility for bus front or rear monitoring systems.

• Fleet Monitoring

Suitable for fleet surveillance and vehicle monitoring systems, helping fleet operators improve driving visibility and safety.

• Vehicle DVR Systems

Can be connected to mobile DVR / vehicle DVR systems for continuous video recording.

• Commercial Vehicle Security

Suitable for logistics vehicles, transportation vehicles and other commercial vehicle applications.

Quality Testing

Each vehicle camera is tested before shipment to ensure stable image quality and reliable operation.

• Image quality test
• Video output test
• Starlight night vision test
• Wide-angle test
• 180° tilt adjustment test
• Mirror / non-mirror image test
• PAL/NTSC test
• Power consumption test
• Connector test
• Waterproof test
• High/low temperature test
• Final appearance inspection

FAQ

Q1: What viewing angle does the camera provide?

The standard viewing angle is 120°, with up to 170° optional.

Q2: Does the camera support night vision?

Yes. It features Starlight Color Night Vision for low-light monitoring.

Q3: Can the camera be used as a front or rear camera?

Yes. The camera supports front and rear vehicle monitoring applications, with mirror and non-mirrored image options.

Q4: Can the camera angle be adjusted?

Yes. The camera supports 180° tilt adjustment.

Q5: Does it support 1080P?

Yes. AHD1080P is available as an optional video configuration.

Q6: Is the camera waterproof?

Yes. The camera has an IP69K waterproof rating.
