4CH 1080P Dual SD Mobile DVR Support HD Output
Carleader 4CH 1080P Dual SD Mobile DVR Support HD Output prefect for fleet management to monitor driver behavior and road route analysis. Support HDMI signal video output for clear monitoring display.
Model:CL-MR601G
Send Inquiry
Product Description
Carleader 4CH 1080P Dual SD Mobile DVR Support HD Output prefect for fleet management to monitor driver behavior and road route analysis. Support HDMI signal video output for clear monitoring display.
Features:
- 4-CH 1080P AHD Dual MDVR
- Support Max 2*512GB SD Card
- 1-CH CVBS,1-CH VGA and 1-CH HDMI Output
- GPS,4G and WIFI Optional Functions
- Support Motion Detection & RTSP Stream
- 1-CH USB Port for Mouse & Video Back up
- Support Wialon & CMSV6 Server for Monitoring
- Dimension (LxWxH): 148*146*40mm
Parameter:
|
Main Feature |
Parameters |
Performance |
|
SYSTEM |
System |
Linux |
|
Language |
Chinese/English/Russia etc |
|
|
Interface |
Visual GUI, Support Mouse |
|
|
Account Management |
Admin / Sub-User management |
|
|
RECORD |
Video Standard |
PAL/NTSC |
|
Video Input |
4-CH AHD Input (1080P/720P/D1) |
|
|
Video Output |
1-CH CVBS + 1-CH VGA Output+1-CH HDMI |
|
|
Video Compression |
H.264 |
|
|
Recording Mode |
Boot up/Manual/Schedule/Alarm Record |
|
|
Motion detection |
Support |
|
|
Audio |
Audio Input |
4-CH Audio input |
|
Audio recording |
Audio & Video synchronized recording |
|
|
Audio Compression |
G.726 |
|
|
Audio Output |
1-CH Audio Output |
|
|
Playback |
Playback Mode |
Playback by Time / File / Channel / Event |
|
Playback Channel |
4-CH Local Playback |
|
|
Interface |
I/O Alarm Input |
4-CH |
|
I/O Alarm Output |
1-CH |
|
|
RS232 Ports |
support |
|
|
RS485 Ports |
N/A |
|
|
USB Port |
Support |
|
|
Ethernet Port |
N/A |
|
|
Wireless Module |
4G LTE |
Support |
|
GPS |
Support |
|
|
WIFI |
Optional | |
|
Others |
Pre-Recording |
0 ~ 15s |
|
Post-Recording |
15 ~ 300s | |
|
G-sensor |
Support | |
|
Local Upgrade |
Upgrade by USB Port |
|
|
Remote Upgrade |
Remote Upgrade by 3G/4G |
|
| Data Storage |
2x SD Card Slot, each up to 512GB |
|
|
Voltage Input |
DC8-36V |
|
|
Temperature |
-20℃ - +70℃ |
|
|
Dimension(L*W*H) |
148mm*146mm*40mm |
