7 Inch IPS Commercial Vehicle AHD Monitor Support CarPlay Multimedia

Carleader Newly Launched 7 Inch IPS Commercial Vehicle AHD Monitor Support CarPlay Multimedia, a High-End AHD vehicle monitor with 7 inch IPS HD Panel, offer a HD display solution with clarity. Integrate with CarPlay Multimedia function, compatible with Android Auto. Welcome to ask for more details.

Model:CL-S776AHD

Send Inquiry

Product Description

Features:

* 7" IPS high digital panel with 16:9 image ratio, 1024 x 600 (RGB) resolution.

* 2CH AHD camera inputs, 3CH input also available.

* Video format available for AHD 720P/1080P, compatible for CVBS camera.

* 2CH / 3CH trigger wires inputs, CH2 has trigger priority, with trigger delay function to be adjust in menu.

* Support CarPlay and Android Auto Multimedia Function.

* Built-in High quality audio speaker.

* Full function remote control (Pack with 1x remote in the box)

* Screen touch contril.

* Auto Dimming function optional (Without auto dimming as default), support to adjust the screen brightness automatically base on the surrounding light intensity.

* Multi-language menu setting.

* Wide working voltage: 9~32V

Parameter:

7 Inch IPS Commercial Vehicle AHD Monitor Support CarPlay Multimedia
Model	CL-S776AHD
Screen Type	7 inch IPS LCD panel
Aspect Ratio	16 : 9
Resolution	1024 x 600 (RGB)
Brightness	450 cd/m2
Contrast	500 : 1
Video Input	Support 2CH / 3CH AHD 1080P/720P/CVBS Mixed Video Signal Input available With 2 / 3 x trigger wires, CH2 has trigger priority
Multimedia	Support CarPlay and Android Auto Multimedia Function Wired and Wireless connection to cellphone Phone Dialing, Message Sending, Map Navigation, Music Player, etc.
Speaker	Yes
Auto Dimming	Optional (Without as default)
Remote Control	Yes, Package include 1x remote
OSD Menu	Image Setting, Image mirrored, Blue/Black Screen (No Signal), Multi-Language Setting, Trigger Delay, Parking Guide Line On/Off, Reset
System	PAL / NTSC auto switch
Button Type	Click Buttons on the top of the monitor
Touch Screen	Yes
Bracket	Include a fan feet Bracket
Power Supply	DC 9~32V
Connection Plug (Connector)	4-PIN Aviation Connector
Operating Temperature	-20°C~+70°C (RH0%-RH90%)
Storage Temperature	-30°C~+80°C (RH0%-RH90%)
Warranty	2 Years
Dimension	17.4 x 11.5 x 2.2 cm
