7 Inch IPS Screen 2CH AHD Input Touch Buttons Heavy Vehicle Monitor

Carleader 7 Inch IPS Screen 2CH AHD Input Touch Buttons Heavy Vehicle Monitor, the 7 inch AHD car TFT LCD screen display has a unique appearance design. You can rest assured to buy 7 inch Touch Buttons 2AV AHD Vehicle Monitor from our factory and we will offer you timely delivery and the best after-sale service.

Model:CL-S776AHD

Send Inquiry

Product Description

Carleader 7 Inch IPS Screen 2CH AHD Input Touch Buttons Heavy Vehicle Monitor, a cutting-edge AHD monitor features with IPS display screen perfect work with large view angle camera, 2CH AHD signal inputs with trigger wires, compatible with CVBS / AHD 720P / AHD 1080P cameras, PAL / NTSC system auto switch.

Parameter:

7 Inch IPS Screen 2CH AHD Input Touch Buttons Heavy Vehicle Monitor
Model	CL-S776AHD
Screen Type	7 inch IPS LCD panel
Aspect Ratio	16 : 9
Resolution	1024 x 600 (RGB)
Brightness	450 cd/m2
Contrast	500 : 1
Video Input	Support 2CH / 3CH AHD 1080P/720P/CVBS Mixed Video Signal Input available With 2 / 3 x trigger wires, CH2 has trigger priority\
Speaker	Optional (Without as default)
Audio Mode (If With Speaker)	CH1 with audio function
Auto Dimming	Optional (Without as default)
Remote Control	Yes, Package include 1x remote
OSD Menu	Image Setting, Image mirrored, Blue/Black Screen (No Signal), Multi-Language Setting, Trigger Delay, Parking Guide Line On/Off, Reset
Parking Guide Line	Each channel is adjusted separately, activated when trigger the trigger wire (Off as default)
Mirror / Normal Image	Each channel is adjusted separately (Mirror image as default)
System	PAL / NTSC auto switch
Button Type	Touch buttons, each button with backlight
Power Supply	DC 9~32V
Connection Plug (Connector)	4PIN aviation connector as default, customized to RCA connector available
Operating Temperature	-20°C~+70°C (RH0%-RH90%)
Storage Temperature	-30°C~+80°C (RH0%-RH90%)
Warranty	2 Years
Dimension	17.4 x 11.5 x 2.2 cm
