AI Detection 720P AHD Car Camera
Carleader is a profession AI Detection 720P AHD Car Camera manufacturer and supplier in China. We have been specialized in car monitoring for many years. Our products have a good price advantage and cover most of the European and American markets. We look forward to becoming your long-term partner in China.
Model:CL-927AI
Send Inquiry
Product Description
AI Detection 720P AHD Car Camera Features:
This Carleader’s advanced AI car camera can detect pedestrians and vehicles in rough 5 meters distance.
CL-927AI has 720P high resolution
camera which could offer you clear display. When it detect the moving
pedestrians and vehicles, it will make a warning.
In this case, you could have a more safer driving environment.
Parameter AI car camera CL-927AI:
|
Image Device: 1/3”CMOS |
|
Frame Rate: 25 FPS |
|
Effective Pixels: 1280 (H) x 720 (V) |
|
Pixel Size: 3.75 μm x 3.75 μm |
|
Scanning System: Progressive Scanning |
|
Sync. System: Internal |
|
Resolution: 720P |
|
Video Output: 1.0Vp-p, 75Ohm |
|
Gamma Consumption: 0.45 |
|
AGC: Auto |
|
Dynamic rang: 83dB |
|
White Balance: Auto |
|
Electronic Shutter: 1/25 ～1/50,000 Seconds |
|
BLC: Auto |
|
Operating Temperature: –20℃ ~ 70℃, RH95%MAX. |
|
Storage Temperature: –40℃ ~ 80℃, RH95%MAX. |
|
Power Supply: DC9-32V |
|
Waterproof rating: IP69K |
|
Viewing Angle: 135° |
|
Audio: No, the audio channel take by alarm |
|
Minimum Illumination □ 0.01 Lux/F1.2 □0 LUX with IR |
|
Image mode Mirror/Normal |
AI car camera CL-927AI Application:
For medium and large vehicles (typically such as commercial vehicles, such as buses, muck trucks, etc.),
the front view CL-927AI camera should be installed in the middle and lower part of the windshield close to the bottom,
within 10cm from the left and right of the central axis of the vehicle.
Precautions for AI 720P AHD Car Camera installation：
- Do not touch the camera lens with hands or other objects during installation;
- Remember to tighten the limit screw after installation;
- Be sure to tear off the lens protective film after installation;
- After debugging and calibration, check the camera again.
