Brake Light Camera For Fiat Doblo 2010-Current Opel Combo Rear View Camera

The integrated design combines brake light replacement and backup camera functions, helping drivers reduce rear blind spots and improve driving safety. With CVBS/720P/1080P optional video output, 1.7mm wide-angle lens and 120°-140° viewing angle, this Van Backup Camera provides clear rear images for reversing, parking and fleet operation. The camera features IP69K waterproof protection and 4PIN Aviation Connector with RCA Adapter, ensuring stable connection and easy installation.

Features:

1. AHD Brake Light Camera designed with 1.7mm lens and 120°-140° viewing angle improves rear visibility for reduces blind spots.

2. Supports CVBS/720P/1080P optional video output for different vehicle monitors.

3. 0Lux low illumination performance ensures stable rear monitoring in dark environments.

4. 4PIN Aviation Connector with RCA Adapter provides reliable connection and easy installation.

5. IP69K waterproof protection supports harsh outdoor vehicle environments.

6. AHD Rear View Camera improves reversing and parking safety.

Parameter:

Suitable Model:  FIAT Doblo (2010-Current) ，OPEL Combo(2011-2018)

Effective Pixels: CVBS / 720P / 1080P Optional

Lens: 1.7mm

Video Input Format: CVBS / 720P / 1080P HD25/30fps PAL/NTSC

View Angle: 120°-140°

Connector: 4PIN Aviation Connector

Power Supply: DC12V (Standard), 24V (Optional)

Minimum Illumination: 0Lux

White Balance: Auto

IR LED: N/A

Audio: N/A

Bracket: With LED Light

IP Rating: IP69K

AHD/CVBS Switch Cutting Line Optional

PAL/NTSC Switch Cutting Line Optional

Quality Control & Testing

Each Brake Light Camera is tested before shipment:

• Camera image and video signal test
• Waterproof and dust protection test
• Power supply and connector test
• Aging test for stable operation

FAQ

Q1: Which vehicles does this Brake Light Camera fit?

A: It fits Fiat Doblo (2010-Current) and Opel Combo (2011-2018).

Q2: Does it replace the original brake light?

A: Yes, it is designed as a third brake light replacement camera.

Q3: Does it support 1080P?

A: Yes, CVBS/720P/1080P optional video output is available.

Q4: Is it waterproof?

A: Yes, the camera features IP69K waterproof protection.

Q5: How does it connect?

A: It uses a 4PIN Aviation Connector with RCA Adapter for easy installation.
