VW T6 Tailgate Backup Camera With LED Brake Light For Commercial Vehicle

The camera maintains the vehicle's original appearance while adding backup camera functionality. With a 1.7mm wide-angle lens and 120°-140° viewing angle, it helps drivers achieve a wider rear view and reduce blind spots during reversing. Supporting CVBS/720P/1080P optional video output, this VW T6 Backup Camera is compatible with various vehicle monitors and DVR systems.

The camera features IP69K waterproof protection, 0Lux low illumination performance and 4PIN Aviation Connector with RCA Adapter, making it suitable for professional vehicle installations.

Features:

1. VW T6 Backup Camera provides 120°-140° wide rear visibility for safer reversing and parking.

2. 1.7mm wide-angle lens offers improved rear coverage and reduces blind spots.

3. Supports CVBS/720P/1080P optional video output for different display systems.

4. LED Brake Light Camera maintains OEM vehicle appearance after installation.

5. 0Lux low illumination performance ensures reliable operation in low-light conditions.

6. 4PIN Aviation Connector with RCA Adapter provides stable connection and easy installation.

Parameter:

Suitable Model: VW T6 Tailgate Single Door(2016-Current)

Effective Pixels: CVBS / 720P / 1080P Optional

Lens: 1.7mm

Video Input Format: CVBS / 720P / 1080P HD25/30fps PAL/NTSC

View Angle: 120°-140°

Connector: 4PIN Aviation Connector

Power Supply: DC12V (Standard), 24V (Optional)

Minimum Illumination: 0Lux

White Balance: Auto

IR LED: N/A

Audio: N/A

Bracket: With LED Light

IP Rating: IP69K

AHD/CVBS Switch Cutting Line Optional

PAL/NTSC Switch Cutting Line Optional

FAQ

Q1: Which vehicle does this Brake Light Camera fit?

A: It is designed for VW T6 Tailgate Single Door models from 2016-current.

Q2: Does it replace the original brake light?

A: Yes, it replaces the original third brake light position and integrates the camera function.

Q3: Does it support 1080P?

A: Yes, CVBS/720P/1080P optional video output is available.

Q4: Is the camera waterproof?

A: Yes, it features IP69K waterproof protection.

Q5: How does it connect to the monitor?

A: It uses a 4PIN Aviation Connector with RCA Adapter for easy installation.
