Day Night Rear View Camera with 50 degree/120 degree Viewing Angle for Commercial Vehicles

What Makes This Camera Different

1. Choose the View You Actually Need

The two lens options give distributors and installers more flexibility:

• 6mm / 50° – narrower, more focused rear-area monitoring
• 2.8mm / 120° – wider coverage for larger rear monitoring areas

This makes the camera easier to match with different vehicle sizes and mounting positions.

2. Automatic Day & Night Switching

The built-in IR-Cut function automatically switches between day and night imaging according to surrounding light conditions, making the camera suitable for continuous vehicle monitoring.

3. Designed for Low-Light Conditions

With 0.01 LUX minimum illumination and 10 LED, the camera provides additional visibility when the vehicle operates in darker environments.

4. AHD Video Compatibility

CVBS, AHD720P and AHD1080P options allow the camera to work with different generations of vehicle monitor, DVR and MDVR systems.

5. Built for Commercial Vehicles

The IP69K rating makes it suitable for exterior installation where the camera may encounter rain, road spray, dust and vehicle washing.

Parameters

Product Type: Rear View Camera

Image Sensor: 1/2.7″ & 1/3″

Video Input: CVBS / AHD720P / AHD1080P Optional

Power Supply: DC12V Standard, 24V Optional

Mirror Image: Optional

Non-Mirrored Image: Optional

Minimum Illumination: 0.01 LUX (10 LED)

Lens: 6mm (50°) / 2.8mm (120°)

IR-Cut: Day and Night Switch Automatically

System: PAL / NTSC Optional

View Angle: 50° / 120°

Waterproof Rating: IP69K

Operating Temperature: -20℃~+75℃ (RH95% Max.)

Storage Temperature: -30℃~+85℃ (RH95% Max.)

Where It Fits

• Truck Reversing Camera

For trucks requiring rear visibility during reversing, parking and maneuvering.

• Trailer Rear Camera

The 120° option can provide broader coverage behind trailers and long vehicles.

• Bus Rear Monitoring

Suitable for monitoring the rear area of buses and coaches.

• Fleet Camera System

Can be integrated into multi-camera fleet surveillance and MDVR systems.

• Commercial Vehicle Safety

Useful for vehicles requiring additional visibility around the rear body area.

• Focused Rear Monitoring

The 50° configuration can be considered when a narrower viewing perspective is preferred.

Quality Control

• Relevant inspections can include:
• Day/night switching function inspection
• Video signal and image output testing
• Viewing angle verification
• Low-light performance inspection
• LED illumination testing
• Waterproof protection inspection
• Power supply testing
• Mirror/non-mirrored image verification
• Operating temperature testing

FAQ

Q: What viewing angles are available?

A: The camera is available with a 50° or 120° viewing angle, corresponding to 6mm and 2.8mm lens options.

Q: Does it switch between day and night automatically?

A: Yes. The camera has an IR-Cut automatic day/night switching function.

Q: Is 1080P available?

A: Yes. AHD1080P is available, together with CVBS and AHD720P options.

Q: Can it be used on trucks and trailers?

A: Yes. It is designed for trucks, buses, vans, trailers and other commercial vehicles.

Q: Is it suitable for outdoor installation?

A: Yes. The camera has an IP69K waterproof rating.
