Heavy Duty Rear View Camera for Trucks, Buses and Commercial Vehicles
Products
Vehicle Monitor & Camera Manufacturer New Products
Heavy Duty Rear View Camera for Trucks, Buses and Commercial Vehicles
Carleader Heavy Duty Rear View Camera for Trucks, Buses and Commercial Vehicles. The Rear View Camera is built for reliable rear-area visibility on trucks, buses, vans, trailers and other commercial vehicles. Its 120° viewing angle provides broad coverage behind the vehicle, while 0.01 LUX low-light performance and 18 LED illumination support monitoring in dark environments. CVBS, AHD720P and AHD1080P options allow integration with different vehicle monitors, DVRs and MDVRs. With an aluminum alloy housing and IP69K protection, this truck rear camera is suitable for reversing, fleet monitoring and commercial vehicle surveillance.
Model:CL-800
Send Inquiry
Product Description
Carleader Heavy Duty Rear View Camera for Trucks, Buses and Commercial Vehicles. This vehicle rear view camera is designed for applications where clear rear visibility is important during daily vehicle operation, reversing and fleet monitoring. It can be used as a truck rear camera, bus rear camera or commercial vehicle backup camera, depending on the installation and monitoring system which supports CVBS, AHD720P and AHD1080P, providing compatibility with different vehicle displays and recording equipment. A 2.8mm lens and 120° viewing angle offer a practical balance between rear-area coverage and image perspective. For darker environments, the camera provides 0.01 LUX low-light performance with 18 LED illumination, giving it a strong focus on nighttime and low-light vehicle monitoring. The aluminum alloy housing and IP69K waterproof rating further suit exterior installation on working vehicles.
Why This Rear Camera
1. Designed Around Rear Visibility
Rather than being a general-purpose camera, this model is positioned specifically for rear view and backup monitoring, making it suitable for vehicles that need additional visibility behind the body.
2. 0.01 LUX Low-Light Performance
The 0.01 LUX specification combined with 18 LED illumination helps provide additional visibility when natural or surrounding light is limited.
3. 120° Wide Viewing Angle
The 120° view angle provides broad rear coverage for reversing, maneuvering and general vehicle surveillance.
4. AHD1080P Available
With AHD1080P optional, the camera can be integrated into HD truck camera systems, vehicle DVR systems and fleet monitoring solutions.
5. Aluminum Alloy Housing
The aluminum alloy construction provides a robust housing option for exterior vehicle camera installation.
6. IP69K Protection
IP69K protection makes the camera suitable for demanding outdoor environments involving water, dust and regular vehicle washing.
7. Flexible Image Configuration
Mirror and non-mirrored image options allow the camera to be configured according to the actual viewing position.
Product Parameters
Product Type: Rear View Camera
Image Sensor: 1/2.7″ & 1/3″
Video Input: CVBS / AHD720P / AHD1080P Optional
Power Supply: DC12V Standard, 24V Optional
Mirror Image: Optional
Non-Mirrored Image: Optional
Minimum Illumination: 0.01 LUX (18 LED)
Lens: 2.8mm
System: PAL / NTSC Optional
View Angle: 120°
Waterproof Rating: IP69K
Housing: Aluminum Alloy
Built-in Microphone: Optional
Operating Temperature: -20℃~+75℃ (RH95% Max.)
Storage Temperature: -30℃~+85℃ (RH95% Max.)
Application Scenarios
- Truck Rear Monitoring
Provides additional visibility behind trucks and heavy-duty vehicles during operation and reversing.
- Commercial Vehicle Backup Camera
Suitable for vans, buses, trailers and other commercial vehicles requiring rear-area monitoring.
- Fleet Camera Systems
Can be integrated with DVR or MDVR equipment as part of a broader fleet surveillance system.
- Nighttime Vehicle Monitoring
The 0.01 LUX specification and 18 LED illumination make it suitable for low-light monitoring applications.
- Loading & Unloading Areas
Provides a rear camera view to assist monitoring around the vehicle during loading, unloading and maneuvering.
FAQ
Q: What vehicles can use this rear view camera?
A: It is suitable for trucks, buses, vans, trailers and other commercial vehicles.
Q: Does it support 1080P?
A: Yes. CVBS, AHD720P and AHD1080P versions are optional.
Q: What makes this camera suitable for nighttime use?
A: It has a 0.01 LUX specification and 18 LED illumination for low-light applications.
Q: What is the viewing angle?
A: The camera provides a 120° viewing angle.
Q: Can it be used with an MDVR?
A: Yes, it can be integrated with compatible DVR, MDVR and vehicle monitoring systems.
Q: Is it suitable for exterior installation?
A: Yes. The camera uses an aluminum alloy housing and has an IP69K waterproof rating.
