Ultra Wide Angle Vehicle Backup Camera for Commercial Vehicles
Carleader Ultra Wide Angle Vehicle Backup Camera for Commercial Vehicles. The 170° Rear View Camera is designed for trucks, buses, trailers and other commercial vehicles that require an extra-wide rear viewing area which provides broad coverage behind the vehicle and can help reduce blind areas during reversing and maneuvering. The camera supports CVBS, AHD720P and AHD1080P, while 0.01 LUX low-light performance with 10 LED illumination supports nighttime monitoring. IP69K protection makes it suitable for demanding exterior vehicle applications.
Model:CL-802
Send Inquiry
Product Description
Carleader Ultra Wide Angle Vehicle Backup Camera for Commercial Vehicles. This ultra wide angle vehicle camera is designed for applications where conventional rear cameras may not provide sufficient coverage. With its 170° viewing angle, the camera can capture a much wider area behind the vehicle, making it suitable for truck rear monitoring, reversing, maneuvering and vehicle blind-spot observation. The camera supports CVBS, AHD720P and AHD1080P, allowing integration with different vehicle monitors, DVRs and MDVR systems. Mirror and non-mirrored image options provide additional installation flexibility. For low-light applications, the camera offers 0.01 LUX performance with 10 LED illumination. Its IP69K protection makes it suitable for exterior installation on commercial vehicles operating in demanding road environments.
Key Advantages
1. 170° Ultra Wide Viewing Angle
The 170° viewing angle is the key feature of this truck rear camera, providing extensive rear-area coverage for reversing and maneuvering.
2. Wide-Angle Lens
The 2.1mm lens works with the 170° viewing angle to create a broad field of view around the rear of the vehicle.
3. Low-Light Monitoring
With 0.01 LUX minimum illumination and 10 LED lights, the camera is designed for applications where visibility is required in darker conditions.
4. Multiple Video Formats
CVBS, AHD720P and AHD1080P options make the camera adaptable to different vehicle camera systems.
5. Built for Exterior Vehicle Use
IP69K protection helps the camera withstand demanding outdoor conditions, including water, dust and vehicle washing.
6. Flexible Image Direction
Mirror and non-mirrored image options allow the camera to match different mounting and display requirements.
Parameters
Product Type: Rear View Camera
Image Sensor: 1/3" Sony CCD
Video Input: CVBS / AHD720P / AHD1080P Optional
Power Supply: DC12V Standard, 24V Optional
Mirror Image: Optional
Non-Mirrored Image: Optional
Minimum Illumination: 0.01 LUX (10 LED)
Lens: 2.1mm
S/N Ratio: ≥48dB
System: PAL / NTSC Optional
View Angle: 170°
Video Output: 1.0Vp-p, 75Ω
Waterproof Rating: IP69K
Operating Temperature: -20℃~+75℃ (RH95% Max.)
Storage Temperature: -30℃~+85℃ (RH95% Max.)
FAQ
Q: What is the viewing angle of this rear camera?
A: It provides a 170° ultra-wide viewing angle.
Q: What image sensor does it use?
A: The camera uses a 1/3" Sony CCD image sensor.
Q: Does it support AHD1080P?
A: Yes. CVBS, AHD720P and AHD1080P are optional.
Q: Is it suitable for trucks?
A: Yes. It is designed for trucks, buses, trailers and other commercial vehicles.
Q: Can it be used at night?
A: Yes. It supports 0.01 LUX low-light performance with 10 LED illumination.
Q: Is it waterproof?
A: Yes. The camera has an IP69K waterproof rating for exterior vehicle applications.
Quality Control
- Relevant inspections can include:
- Image and video output testing
- 170° viewing angle verification
- Low-light performance inspection
- LED illumination testing
- Waterproof protection inspection
- Power supply testing
- Operating temperature testing
- Mirror/non-mirrored image inspection
- Housing and assembly inspection
