Waterproof Side View Camera for Commercial Vehicles with Day Night Vision

Main Highlights

1. Wide Side Coverage

The 140° side view camera provides a broad field of view for monitoring areas beside the vehicle.

2. Useful for Blind Spot Areas

An additional side-facing camera can improve visibility around vehicle side areas that may be difficult to observe directly.

3. Automatic Day/Night Switching

The IR-cut function automatically switches between day and night modes according to ambient lighting.

4. Low-Light Illumination

The camera uses 5 LEDs to support visibility in low-light conditions.

5. CVBS & AHD Options

CVBS, AHD720P and AHD1080P versions are available for different vehicle video systems.

6. Left or Right Side Installation

Mirror and non-mirrored image configurations make the camera suitable for different side mounting positions.

7. IP69K Protection

The IP69K-rated housing is suitable for exterior vehicle applications and demanding operating environments.

8. Optional Built-in Microphone

A built-in microphone is available as an option for applications requiring audio monitoring.

Where It Can Be Used

The camera is suitable for different types of vehicle monitoring, including:

• Truck side view monitoring
• Commercial vehicle blind spot monitoring
• Van side camera systems
• Bus side monitoring
• Fleet vehicles
• Delivery vehicles
• Logistics trucks
• Construction vehicles
• Vehicle surveillance systems
• Multi-camera vehicle monitoring systems

For larger vehicles, it can also be combined with front and rear view cameras to create a more complete vehicle monitoring system.

Parameters

Product Type: Vehicle Side View Camera

Video Input: CVBS / AHD720P / AHD1080P Optional

Power Supply: DC12V (Standard), 24V (Optional)

Image: Mirror Image & Non-Mirrored Image Optional

Minimum Illumination: 0.5 LUX (5 LED)

Lens: 2.0mm

Day/Night Function: IR Cut Day and Night Switch Automatically

System: PAL/NTSC Optional

S/N Ratio: ≥48dB

View Angle: 140°

Waterproof Rating: IP69K

Built-in Microphone: Optional

Operating Temperature: -20℃~+75℃ (RH95% Max.)

Storage Temperature: -30℃~+85℃ (RH95% Max.)

FAQ

Q1: What is a side view camera used for?

A side view camera provides additional visibility along the side of a vehicle and can be used to monitor areas around vehicle blind spots.

Q2: Is this camera suitable for trucks?

Yes. It can be used on trucks, vans, buses and other commercial vehicles.

Q3: What is the viewing angle?

The camera provides a 140° viewing angle.

Q4: Can it be installed on either side of the vehicle?

Yes. Mirror and non-mirrored image options are available for different installation positions.

Q5: Does it support night vision?

The camera has an automatic IR-cut day/night switching function and 5 LEDs for low-light conditions.

Q6: Does it support 1080P?

Yes. AHD1080P is available, together with CVBS and AHD720P options.
